Revo ObXidian® Nozzles

Revo ObXidian Nozzles
With a wear resistance that is several orders of magnitude higher than any other E3D nozzle, and indeed any other generic hardened steel nozzle on the market, ObXidian® is really hard.

This is achieved by pairing a tool steel insert with our new E3DLC™ coating. This specially formulated coating also embeds non-stick properties into the Nozzle itself. Meaning considerably less plastic build-up around the Nozzle.

Experiment freely. With nozzle swapping this easy, you’re free to experiment with different nozzles for different applications. Swap out your Revo brass nozzles with an ObXidian between prints to unlock fibre-filled fun.

Frustration-free. Each Revo Nozzle is a preassembled nozzle and HeatBreak in one unit, so there’s no hazardous hot tightening and no chance of incorrect assembly. Say goodbye to frustrating HotEnd leaks and enjoy reliable 3D printing!

Rapid identification. Identify nozzle sizes at a glance, thanks to a colour-coded silicone sock. Plus, each Revo Nozzle has its size engraved into it with easy-to-read numbers, so there are no confusing identification markers to learn!

Please note:

• Revo® Nozzles are not compatible with V6-style heaterblocks
• You may need to adjust your Z offset when changing nozzles.
• ObXidian® coated nozzles are exceptionally wear resistant compared to other products on the market and significantly outperform other hardened nozzles. Improvements in ‘exotic’ engineering filaments mean that some new materials which include aggressive fillers, including but not limited to Polymaker’s PolyMide range (PA612-CF, PA6-CF, PA6-GF and PA12-CF), can cause significant wear on even ObXidian nozzles. E3D is actively developing even more specialist solutions for these materials. In the meantime please be aware that even the rainbows and unicorns in your ObXidian nozzle are not everlasting under extreme material conditions.

• Some filled materials contain particles that are close to, if not larger than, some of the smaller industry standard nozzle sizes, including up to 0.4mm. Attempting to print such materials through these nozzle sizes significantly increases the risk a jam. Please check your filament manufacturer’s datasheet for recommended minimum nozzle orifice diameter to ensure that the nozzle/hotend you choose is suitable for your use case.
